This repository is organised as follows:
- /robot_runner: Contains the experiment configuration;
- /data: Contains the experiment's run table (with aggregated measurements per run as well as their configuration);
- /analysis: Contains all scripts used for data analysis;
- /figures: Contains all figures created during data analysis;
- /ros_packages: Contains all custom ROS packages for measuring power consumption, CPU utilisation and memory utilisation.
The experiment is designed and executed using Robot Runner: a software framework for orchestration and (partial) automation of measurement-based robotics experiments. The structure is as follows:
/robot_runner
|--- /documentation Robot Runner documentation
|--- /robot-runner Robot Runner core
|--- /experiments
| |--- /slam_experiment All experiment scripts
| | |--- /turtlebot The mission package running on the Turtlebot
| | | |--- /config Configuration files for all algorithms and parameter settings in the experiment
| | | |--- /launch Launch files for all evaluated algorithms
| | | |--- /rosbags Movement instructions for traversing the arenas
| | |--- config.py Definition of all steps in the experiment associated with event hooks in Robot Runner
The full dataset of all measurements is too large for GitHub, but can be obtained from Google Drive. Each subdirectory of contains the measurement data related to one of the 320 experiment runs. The structure is as follows:
/data
|--- /run_<i> The results for the ith experiment run
| |--- <i>.bag Topic data recorded during the experiment
| |--- <i>.pgm A map created using map_server after completing traversal of the arena
| |--- <i>.txt Log of all terminal output for the current run
| |--- cpu_mem_measurements.csv Raw measurements for CPU and memory utilisation
| |--- energy_measurements.csv Raw measurements for power consumption
| |--- final_map.csv Final occupancy grid, used for analysis
| |--- rosbag_measurements.csv Time, topic and size for all ROS messages
| |--- trimmed_cpu_mem_measurements.csv Measurements trimmed to 1 second after the last nonzero velocity, to avoid the influence of profiler timing issues
| |--- trimmed_energy_measurements.csv Measurements trimmed to 1 second after the last nonzero velocity, to avoid the influence of profiler timing issues
|
|--- run_table.csv Aggregated experiment results
|--- run_table_map_data.csv Aggregated experiment results including map analysis metrics (computed after the experiment was performed)
Each subdirectory of /analysis contains R and Jupyter notebooks for a particular metric in the experiment:
/analysis
|--- /<metric>
| |--- <metric>_arena_circular.Rmd R notebook containing the statistical analysis for the circular arena
| |--- <metric>_arena_circular.nb.html HTML export of the above R notebook
| |--- <metric>_arena_point_to_point.Rmd R notebook containing the statistical analysis for the point to point arena
| |--- <metric>_arena_point_to_point.nb.html HTML export of the above R notebook
|
|--- correlations_analysis.Rmd R notebook containing the statistical analysis of correlation between metrics (using Spearman's correlation coefficient)
|--- correlations_analysis.nb.html HTML export of the above R notebook
|--- result_boxes_overview.Rmd R notebook containing the difference computations for all result boxes in the thesis document
|--- result_boxes_overview.nb.html HTML export of the above R notebook
|--- data_exploration.ipynb Jupyter notebook containing all scripts for plotting measurements over time
For each of the metric and arena combinations, the analysis starts by obtaining descriptive statistics and plotting the data as bar and box plots. Then, the assumptions for ANOVA are tested and (PERM)ANOVA is carried out. As post hoc tests, Tukey's HSD or Dunn's test are used.
The profilers used in this experiment are documented in their respective folders (ros1-ina219-profiler-service and ros1-resource-profiler-service).
